AHP AlphaTIG 225Xi

Description:   New features for 2024!  Now with HV Start (Electronic, solid state simulated HF, no point gap to manage and maintain), and updated internal software, components and controls.  NOVA 2.0 torches with new Silicone Ultra Flexible Lines are included as well.   The AlphaTIG 225Xi is a modern AC/DC TIG/Stick welder with a modular IGBT inverter design that is digitally controlled for top performance. Designed to be versatile, this TIG welder is built to meet the daily needs of  most medium sized fabrication or repair shops.  It features dual voltage 120V/240V input capability for go-anywhere performance with up to 150A output while operating on 120V.  Fully adjustable pulse adds to the theme of versatility with a pulse frequency range in TIG mode up to a respectable 200Hz in both AC and DC modes.  While the unit is designed for the professional welder, the welder is also well within the scope of a beginner welder, with an easy to use interface, and a low entry price when compared to the competition.   Whether professional or novice, this unit features a 3 year, parts and labor warranty. Features Digitally controlled functions and features Internal modular board design Water Cooler Power Outlet on Rear Panel Powerful 225A AC/DC TIG welder (240V) Stick weld with up to 5/32" Stick electrodes with output up to 185A (240V) Adjustable AC TIG and Stick Frequency  Excellent stable arc while welding High Frequency start only 150A output operating on 120v input in TIG mode, (125A in Stick mode)  35% duty cycle @ 225A in TIG mode operating on 240V (60% @ 200A, 240V) Pulse frequency 0.5 to 200Hz 2T/4T function What's in the Box: Alpha TIG 225Xi Nova 26 TIG Torch (12.5ft, 35-70 DINSE Connection, 9mm Quick Connect and a Torch Switch for 2T/4T operation) 250A Stick Electrode Holder (9ft) Work Clamp (6ft) Nova Foot Pedal (25 ft. Cord) Floating Ball Type Billet Brass Argon Regulator 240V to 120v Plug Adapter (NEMA 6-50R to NEMA 15-5P) Basic Consumable Kit (does not include tungsten) Specs: Processes : AC and DC TIG with pulse in AC and in DC, AC and DC Stick Rated Electrical Input: 120/ 240v 50/60 Hz Minimum Amp Start On DC/AC: 10A/20A TIG(GTAW) Duty Cycle (240V): 225A/19V @ 35% Duty Cycle TIG/Stick Open Circuit Voltage (OCV): 75V STICK (SMAW) Duty Cycle (240V): 185 A, 27.4 V @ 35% Duty Cycle @ 40° C MAX Inrush Amps:  120V: 35A, 240V: 31A Effective Rated Amps: 120V: 24A, 240V: 23A Foot Pedal: Nova long life, 25 ft. cable TIG Start type: High Frequency Start (non live trigger/pedal actuated) 2T/4T Torch Trigger Panel Control Sequencer: Yes Start Amps(2t/4t Trigger Function): 5(20)-225A End Amps(2t/4t Trigger Function): 5(20)-225A Pre Flow Time for Gas: 0-10 Seconds Post Flow Time for Gas: 0-25 Seconds Down Slope Time (Ramp Down): 0-10 Seconds AC Balance Control: 10-90% of Electrode Positive AC Frequency Control: 20-200 Hz Pulse Frequency Range: .5-200Hz (AC or DC) Pulse Amp Control: 5-95% of Welding Amps Pulse Time ON/ Pulse Width Ratio: 5-95% of Pulse Amps Weight: 50 lbDimensions: 22 in × 9.25 in × 24 in Min/Maximum Capability Ratings are based off of industry "best practice" standards for single pass. Maximum multi-pass is based off of practical limits given maximum machine amperage and duty cycle. TIG: Minimum DC: .015" Minimum AC: .025" Maximum AC 120V: 1/8" Maximum DC 120V: 3/16" Maximum AC 240V: 5/16" Maximum DC 250V: 3/8" Maximum AC multi-pass: 1/2" Maximum DC multi-pass: 5/8" Stick: This unit is not designed to weld with E6010. 120V: 1/16" to 3/32" Electrode 240V: 1/16" to 5/32" Electrode User Manual/Brochure Download 225Xi Operator's Manual Download Brochure Additional Information/Notes This unit is not designed or intended to weld with E6010. The arc will not be stable.  Consider using E6011 in place of E6010. Generator Requirements This unit must be operated with generators that are rated by the manufacturer's as "Clean power".  Clean power is defined as 5% or less Total Harmonic Distortion (THD).  The minimum required wattage for operation with this unit is 9000 Surge Watts. Operation with generators that are not clean power rated or that do not meet the wattage requirements will void the warranty.
